Description
The Robertshaw® S-86 Single and N-86 Dual Water Valve Series are automatic icemaker valves for residential refrigerator icemakers. The N-86 valve allows individual control of water flow through two outlets by using a single inlet for water to the door and for water to fill the icemaker.
Features and Benefits
- Direct acting armature provides high flow capacity with minimum power requirements
- Encapsulated coil provides high mechanical and dielectric strength, and is moisture resistant
- Unique armature and seat design reduce unwanted particles from entering the armature area
- Armature is designed with clearances which minimize the possibility of jamming due to foreign materials
- Bodies are made of polypro which provides high resistance to corrosion and mineral deposits
- Suitable for applications using water at temperatures up to 160°F (71°C)
| Series Application | Residential Ice Machine Water Valve N-86 Dual |
| Electrical Rating | 120V AC, 50/60 Hz, 35W|120V AC, 50/60 Hz, 20W |
| Body Material | Polypro |
| Inlet Size | 1/4″ flare, loxit or compression |
| Operating Pressure | 20 PSI to 120 PSI |
| Outlet | 7/16″ 20 UNF|1/2″ 20 UNF |
| Terminals | 1/4″ Male|3/16″ Male |
| Flow Rate | 130 CC in 7.5 seconds, 22-38 CC per second |
