Description
Bolton Tools is known for manufacturing only top-notch metalworking machine tools including metal lathes, milling machines, CNC lathes and more.
The BT1440GQT-3 by Bolton Tools is a solidtoolroom metal lathe with a very generous 2-inch spindle bore. Workingwith larger OD material is no problem for this bad boy!
Included with your BT1440G metal lathe isa 6″ 3-jaw chuck, 8″ 4-jaw chuck, 11″ face plate, 4-way turrettool post (quick change optional), steady rest and follow rest.
Large travels and heavy castings, makethis lathe the perfect machine tool for your shop!
STANDARDEQUIPMENT:
1. 6″ 3-jaw chuck and 8″ 4-jaw chuck with reversible jaws;
2. 11″ face plate;
3. Steady rest and follow rest;
4. Full-length splash guard;
5. Two MT3 dead center,one MT5-MT3 sleeve;
6. Pull out chip pan;
7. Working light and coolant pump;
8. Tool box.
| Swing over Bed | 14-3/16″(360mm) |
| Swing over Support | 8-13/16″(224mm) |
| Swing over Gap | 19-3/4″(502mm) |
| Center Height | 7″(180mm) |
| Distance between Centers | 39-3/8″(1000mm) |
| Bed Width | 7-3/8″(187mm) |
| Spindle Bore | 2″(52mm) |
| Spindle Nose | MT5 |
| Taper in Nose | MT5 |
| Cam-lock System | D1-4 |
| Spindle Speed | 70,115, 190, 300, 460, 755,1255, 2000 RPM |
| Cross Slide Travel | 6-11/16″(170mm) |
| Compound Slide Travel | 3-9/16″(95mm) |
| Cutting Tool (Max. Section) | 5/8″× 5/8″ (16 × 16 mm) |
| Imperial Thread | 34Nos. 4 – 56 T.P.I |
| Metric Thread | 26Nos. 0.4 – 7 mm |
| Tailstock Quill Taper | MT4 |
| Tailstock Quill Travel | 3-15/16″(100mm) |
| Motor | 2HP, 220V/60Hz/3-phase |
| Coolant Pump | 1/16HP |
| Shipping Weight | 1450lbs. |
| Crate Size | 76″× 30″ × 35″ |
1440GQTmanual
