Description
Sloan 3782645 – 186 Manual Urinal Flushometer – Top Spud – 0.5 GPF
0.5 GPF, Dual-Filtered Fixed Bypass Diaphragm, Polished Chrome Finish, Single Flush, Sloan Exposed Manual Urinal Flushometer
Features
- Quiet, Exposed, Diaphragm Type, Chrome Plated High Efficiency Urinal Valve
- 3/4″ I.P.S. Screwdriver Bak-Chek Angle Stop with Vandal Resistant Stop Cap
- Vacuum Breaker with Flush Connection
- Spud Coupling and Spud Flange for 3/4″ Top Spud
- Sweat Solder Adapter with Cover Tube and Cast Wall Flange
- Non-Hold-Open Handle and No External Volume Adjustment to Ensure Water Conservation
- High Efficiency flush accuracy
- Diaphragm, Handle Packing and Vacuum Breaker Molded from PERMEX Rubber Compound for Chloramine Resistance
- ADA Compliant Metal Oscillating Non-Hold-Open Handle
- Dual Filtered Fixed Bypass Diaphragm
Specifications
- Flush Volume: 0.5 gpf (1.9 Lpf)
- Finish: Polished Chrome (CP)
- Valve: Diaphragm
- Bypass: Dual-Filtered Fixed Bypass Diaphragm (DFB)
- Valve Body Material: Semi-red Brass
- Fixture Type: Urinal
- Fixture Connection: Top Spud
- Rough-In Dimension: 11-1/2″ (292mm)
- Spud Coupling: 3/4″ (19mm)
- Supply Pipe: 3/4″ (19mm)
PTB1L00620
