Description
1. Suitable process for a variety of ductile metals.
2. Adjustable to cover a size range.
3. Multi-roll burnishing tools for accurate sizing and surface hardening of inner holes.
4. Improves surface irregularities and tool marks to enhance surface finishing as smooth as a mirror.
5. Enhanced corrosion resistance of a surface.
6. Roller burnishing tools need be clamped to rotary equipment processing, such as drill press, lathe, milling, boring, processing center, etc.
7. Can be customized according to customer requirements.
| SKU | SH1500-22 | |
| Model | KC-SH1500 | |
| No. of Roller | 4 | |
| Diameter – A | Imperial (inch) | 0.589 – 0.610 |
| Metric (mm) | 14.95 – 15.50 | |
| Min. Adjustable Graduation | 0.0001″ | |
| Housing | Type | HA1 |
| Dia. – D | 1-3/8″ | |
| 34mm | ||
| Work Length – H | 1-31/32″ | |
| 50mm | ||
| Drive Shank | Type | Straight ø0.472″ |
| Length – C | 1-29/64″ | |
| 37mm | ||
| Packing Size (L × W × H) | 8-45/64″ x 1-39/64″ x 1-39/64″ | |
| 221 x 41 x 41mm | ||
| Net Weight | 0.02 lbs. | |
| 0.01 kg | ||
| Gross Weight | 0.88 lbs. | |
| 0.4 kg |
