The Universal Relay Control Box from Eurofase simplifies the management of your comfort zone, offering control over multiple heaters and enabling the creation of varied heat zones within your space. Ideal for commercial settings like restaurant patios, where customers have individual heat preferences, this control cabinet allows you to adjust each area to precise temperature conditions easily. Enhance comfort and convenience with this recommended addition, ensuring optimal heating control for every environment.
The Universal Relay Control Box facilitates the management of multiple heaters by establishing diverse heat zones within a designated area through the use of 0-10V solid state relays, offering the user the option to incorporate dimming capabilities to the heaters
Details
- 0% To 100% dimming capabilities
- Use to control multiple heaters and create zone control
- Integrate with home automation systems
- Nema 4 rated to withstand indoor and outdoor installations
- Material: Steel
- Location Rating: ETL Listed
- OK for Outdoor Use
- Warranty: 3 Year
- Made In Mexico
Dimensions
| Width | 16.” |
|---|---|
| Height | 16.25″ |
| Depth | 6″ |
| Weight | 19 lbs |
Spec
Input Voltage : 240V
Zone Capacity : 50A
Max. Amperage : 200A
Control Voltage : 0V-10V DC
Mounting Type : Surface mount
Dimension
Height : 16.25”
Width : 16”
Depth : 6”
Weight : 21.15 lb
