Description
Features:
- Mini-tank heaters offer a perfect solution for point-of-use applications (kitchen/bar/utility faucets, etc.) without the need for complicated sizing and calculations
- 3-prong 120V plug means easier installation and no need for complex wiring – simply connect the water lines, plug in and use it
- External adjustable outlet water temperature control
- T&P relief valve included
- Mini storage tank is glass-lined for longer life
- Field-replaceable heating element
- Suitable for floor or wall mounting
- External LED diagnostic light offers feedback and simplifies troubleshooting
- Lead-Free compliant, meets ANSI/NSF 372
- ETL listed for US and Canada
Technical Specifications:
- Electrical Specs: 120V (3-prong standard plug), 12A, 1.44 kW, Single-Phase
- Storage Tank Volume: 2.5 Gallons
- Water Connections: 1/2″ Male NPT (located at top of the unit)
- Operating Temperature Range: 50°F – 140°F (adjustable)
- Max. Operating Pressure: 150 psi
- Tank Recovery Time (at 60°F temperature rise): 15 mins
- Empty Weight: 15.5 lbs
- Dimensions (Width x Height x Depth): 10.91″ x 16.89″ x 11.25″
Warranty:
5-year limited warranty on leaks, 2-year warranty on parts
