Description
Grundfos CMBE-1-44 is a 115V all-in-one booster pump system with adjustable outlet pressure. It’s compact, time-tested and features an advanced control with built-in pressure tank to prevent water pressure fluctuations due to change in demand or inlet pressure.
Installation is easy – simply connect the inlet/outlet pipes, plug the pump into an outlet and set the desired pressure.
Grundfos CMBE system is made using high quality materials, including 304 stainless steel housing & impeller – to ensure a lasting, worry-free performance.
CMBE-1-44 model is ideal for smaller residential applications, including average size single family homes.
Cross-References:
- Grundfos: 15 BMQE 05A-110
Features:
- Ideal pressure booster system for single family homes
- Adjustable output pressure via buttons on top panel
- Easy installation – simply connect the piping, plug into a socket and dial the desired pressure
- No fluctuations due to change in water demand or pump starting/stopping
- Quiet, compact, rugged and reliable design
- Includes 5ft cord w/ plug
- High-efficiency ECM motor uses up to 85% less electricity
- Built-in thermal, dry-run and overload protection
- Grundfos Eye LED displays system status for easy troubleshooting
- Grundfos GO compatible
- 5-way fitting w/ integrated check valve, expansion tank and pressure gauge – included
- cULus Listed; NSF/ANSI 61 & 372, MH26400 Listed
Technical Specifications:
- Head Range: 0-128 ft
- Flow Range: 0-13 GPM
- Connections: 1″ FNPT inlet, 1″ FNPT outlet
- Electrical Specs: 115V, 50/60 Hz, Single Phase, 0.75 kW max, 8 Amps max
- Motor Rating: 1 HP, 360-4000 rpm
- Liquid Temperature Range: 32°F – 140°F
- Max. Ambient Temperature: 131°F
- Max Operating Pressure: 145 psi
- Cut-In Pressure: 7 psi above setpoint
- Enclosure Class: IP55
- Materials: 304 Stainless Steel Housing & Impeller, Cast Iron Flange, Silumin (Alu) Stator Housing, Composite Terminal Box and Fan Cover
- Sound level: 55 db(A)
- Net Weight: 40 lbs
- Dimensions (Depth x Width x Height): 12.80″ x 8.54″ x 17.30″
Warranty:
24 months from the date of installation / 30 months from the date of manufacture
