Description
1. CAT NO taper shank is in conformity with AT3 standard
2. Concentricity of the inner and outer cone: 0.0002″
3. For straight shank end mill.
4. End mill holder comes equipped with setscrews.
5. Rear thread for pull stud is 5/8″ – 11
6. Works on all CAT40 machines.
7. Surface blackening treatment.
8. End mill is held by two set screws.
| Brand Name | Woodhorse |
| Model | CAT40 SLA3/4″ x 3-3/8″ |
| SKU | SM050010 |
| Size | CAT40 |
| Style Name | SLA Type |
| L | 6.062″ |
| L1 | 3-3/8″ |
| H1 | 1″ |
| M | 5/8-18 |
| d | 3/4″ |
| D | 1.75″ |
| TIR | ≤ 0.0002″ |
| Balanced to | G2.5 12000 RPM |
| Type | Fig1 |
| Net Weight | 3.3lbs |
