DESCRIPTION
A great addition to any outdoor lighting job, bistro lights add a touch of elegance and ambience for entertaining, the Brilliance Bistro 12 Volt String Kit comes in 26 ft., 52 ft, 98 ft and 150 ft kit options. Use this low voltage bistro string with the corresponding low voltage string connection accessories for custom length bistro lighting. This string is for use with low voltage lamps only. Dimmable with Brilliance Dimmer and most magnetic transformers. Each kit includes bistro string, and hanging kit. Lamps and connector accessories sold separately.
BISTRO 12 VOLT STRING KIT FEATURES
• Patented design (U.S. Patent D898986S)
• Uses 14 AGW cable and features a waterproof seal
• Two-way mounting holes at each lamp position eliminate the need for zip ties and creates a more secure installation for the life of the string lights
• Fully dimmable
| S14 LAMP REQUIREMENTS | 1W, 12VAC | 2W, 12VAC | 3.5W, 12VAC |
|---|---|---|---|
| Max. # of Lamps | 75 | 50 | 30 |
| Max. Wattage | 125.25 with VA | 117.5 with VA | 117.9 with VA |
| Max. String Length | 150 ft. end-to-end | 100 ft. end-to-end | 60 ft. end-to-end |
Spec
26′ length w/ hanging hardware accessories, lamps not included
Operating Range 12VAC
Total Length 26 ft,
String Lead Length At least 10 inches of lead required for connections
Distance Between Lamp Positions 24 inches between lamps
Connection Accessories Available
Straight Connector: 1 per cable conversion
T Connector: 1 per center feed
End Cap: 1 per string end
Includes Low Voltage Bistro String (14 AWG)
Dimension
26′ length w/ hanging hardware accessories, lamps not included
