Description
Easily convert your cordless, pneumatic or corded drillinto a power pop riveter.
- Easily convert your cordless, pneumatic or corded drill into a power pop riveter
- Includes nose pieces for 3/32″, 1/8″, 5/32″, 3/16″, 7/32″ and 1/4″ for steel, aluminum, copper or up to 7/32″ in stainless
- CNC machined from solid billet aluminum and features Japanese bearings
- Works on up to 0.65″ rivet bodies (#8-8 rivets), maximum stroke of 0.7″
Requirements of cordless driving tool:
- Adjustable torque setting.
- Chuck capacity of hex 6.35 mm (1/4″) shank.
- Min. 12V for aluminum and steel rivets up to 3/16″.
- Min. 14.4V for stainless steel rivets up to 3/16″ and thru 1/4″ in aluminum.
- Min. 16V+ for 7/32″ in steel and stainless and 1/4″ in steel. (1/4″ stainless mandrel and body is not recommended and may overheat the tool)
Requirements of electric or pneumatic driving tool:
- Chuck capacity of hex 6.35 mm (1/4″) shank.
- With maximum torque >190 in/lbs for aluminum and steel rivets up to 3/16″ and 7/32″ + 1/4″ in aluminum.
- With maximum torque >330 in/lbs for stainless steel rivets up to 3/16″ and 7/32″ + 1/4″ in steel.
Specifications
- Hex Shank Size: 1/4″
- Rivet Type:Blind Rivet
- Weight: 3 lbs
