Pinpoint Cable Nicks and Cuts
Easily Locate Ground Faults in Underground Cables or Wires
The GFL3000™ is designed to pinpoint nicks or cuts in underground cables or wires where voltage is leaking to ground. The GFL3000™ transmits a powerful pulsed charge that is detected by the receiver at the top of the A-Frame. The receiver has an analog meter that kicks in the direction of ground faults. Following these kicks will quickly lead you to the exact location where electrical voltage is being lost to ground.
Fantastic Value
The GFL3000™ is a low cost ground fault locator with features previously unavailable at this price point. It has dual power capability, which allows the user to select the resistance level of the fault they wish to pursue, along with easy to read battery condition indicators. In addition, the transmitter features a 12 volt rechargeable battery with both wall and car chargers included. All of this comes in a durable, custom molded case.
Specifications
- Transmitter Battery – 12 V Rechargeable (Included)
- Receiver Battery – 9 V Alkaline NEDA (Not Included)
- Power Output – 2400 or 3400 VDC – Selectable
- Voltage Protection – 240 VAC/400 VDC
- Transmitter Weight – 9 lbs
- A-Frame Weight – 4 lbs
- Warranty – 12 Months
