Description
Tekmar 518 is a simple, yet time-proven and reliable 1-stage (single zone) digital non-programmable thermostat with button interface and large backlit screen. Set by default to measure ambient air temperature, it can also automatically detect a single auxiliary sensor to measure either outdoor, floor or remote room temperature.
Features:
- Simple, straightforward, non-programmable interface
- Large backlit screen
- Compatible with a floor sensor (not included) for radiant heat applications
- Freeze protection
- Made in Canada
Technical Specifications:
- Stages: 1 Heat
- Interface: Button
- Screen: Monochrome, backlit
- Mounting: Vertical
- Electrical Ratings: 10 to 30 VAC, 50/60 Hz, 1.8 VA standby, 56 VA max fully loaded, Class 2
- Setting Temperature Range: 40 to 122°F (4.5 to 50.0°C)
- Relay: 30 VAC, 2 A, Class 2 circuits
- Sensor: NTC thermistor (not included)
- Ambient conditions: Indoor use only, 32 to 122°F, RH≤90% non-condensing
- Enclosure material: White PVC Plastic, NEMA type 1
- Dimensions: 3-11/16″ x 3″ x 15/16″
- Packaged weight: 0.53 lbs
Warranty:
3-year warranty
