The 406 compact drain pump comes pre-assembled and ready to install. This short profile design makes it ideal for compact areas of only 10 in. This pump can be used in bar sinks, laundry trays, dehumidifiers, utility sinks, gray wastewater drainage below gravity lines, and showers
1/6 hp 17 AMPS 115 Volts 60Hz
1″, 1.25″, and 1.5″ Discharge
1/8″ Solids Handling
Features
- Factory pre-assembled, ready to install
- Quiet automatic operation
- Short profile design for compact areas – only 10″ tall (base to top inlet flange)
- Float switch and pump serviceability via access cover
- Wet-end serviceability via removable pump “cartridge” – simple, 1/4 turn removal
- Rubber gasket for a superior gas-tight seal
- Floor-level side inlets, with integral check valve and couplings included for convenient plumbing
- Stepped discharge adapter – 1″, 1.25″, 1.5″ with integral check valve
- • Compact design for tight areas and in cabinets
- • Integral check valve at bottom inlet connections
- • Float switch can be accessed and serviced without disconnecting piping
- • Air-cooled motor with thermal-overload protection
- • 9′, 3-wire power cord with grounded plug
- • Corrosion-resistant ABS basin with molded-in connections
- • Maintenance free, permanently lubricated sealed bearings
- • 1/8″ Solids handling
Applications
- Bar sinks
- Laundry trays
- Dehumidifiers
- Utility sinks
- Gray wastewater drainage
- Showers
Maximum Fluid Temperature
104°F (40°C) continuous duty
140°F (60°C) intermittent duty (10 seconds on/5 seconds off)
Included Connection Kit:
• 1 Stepped discharge adapter – 1″, 1.25″, 1.5″, with integral check valve
• 1 Side inlet coupling (1.5″) with integral check valve
• 1 Top vent coupling (1.5″)
• 1 Top inlet coupling (1.5″)
• 2 Pre-installed side inlet plugs
• 1 Pre-installed top inlet plug
• 7 Stainless-steel clamps
